| Dimensions | 305.8 x 118.9 x 100.8 mm |
| Certifications | CE, FCC, ROHS, WEEE, KC, FDA, UKCA, IP50, TELEC, TISAX |
| Supported file formats | OBJ, STL, ASC, PLY, P3, 3MF |
| Accuracy certification | VDl/VDE 2634 Part3 (certificated in ISO 17025 certificated accuracy lab) |
| Connection standard | USB 3.0 |
| Laser class | Class II (eye safe) |
| Light source | 50 laser lines, single laser line, 7 parallel laser lines |
| Max. scan range | 600 x 550 mm |
| Photogrammetry | Built-in scale bar photogrammetry mode |
| Point distance | 0.01–10 mm |
| Power input | 24V, 3.75A |
| Recommended computer configuration | OS: Win 10, 64 bit; Graphics card: NVIDIA GTX/RTX series cards, higher or equal to GeForce RTX 3060; Video memory: ≥6 GB; Processor: I7-8700; Memory: ≥32 GB |
| Scan accuracy | Up to 0.02 mm |
| Scan depth | 170–680 mm |
| Scan mode | Multiple Lines Scan, Single Line Scan, Fine Scan |
| Scan speed | Up to 3,460,000 points/s |
| Volumetric accuracy | 0.02 mm + 0.03 mm/m (standard mode); 0.02 + 0.015 mm/m (built-in photogrammetry mode) |
| Working distance | 300 mm, 200 mm |
| Working humidity | 10% – 90% |
| Working temperature | -20–40 °C |
| Texture / Colors | No |
| Technology | Laser |
| Weight | 950 g |
