| Accuracy | Up to 0.05 mm (in White Light mode), up to 0.1 mm (in IR mode) |
| Certifications | CE, FCC, ROHS, WEEE, KC |
| Connectivity | USB 3.0 |
| Manufacturer | Shining 3D |
| Manufacturer country | China |
| Operating humidity | 10–90% |
| Weight kg | 731.1 g |
| Technology | White light, infrared light |
| Alignment | Markers (for White Light mode only), Feature, Hybrid, Texture, Global markers (for IR mode only) |
| Camera frame rate | 55 FPS |
| Computer requirements (recommended) | OS: Win10, 64-bit; Graphics card: NVIDIA GTX1060; Video memory: ≥4GB; Processor: Intel I7-8700; Memory: ≥16GB |
| Depth of field | 200–700 mm (in White Light mode), 200–1500 mm (in IR mode) |
| Field of view | 420 x 440 mm (in White Light mode), 780 x 900 mm (in IR mode) |
| Output formats | PLY, OBJ, STL, ASC, P3, 3MF |
| Point distance | 0.2–3 mm |
| Safety | Eye-safe |
| Scan and align speed | 1200000 points/s (in White Light mode), 1060000 points/s (in IR mode); 20 FPS |
| Software | ExScan Pro |
| Volumetric accuracy | 0.05±0.1 mm/m (in White Light mode), 0.1mm±0.3 mm/m (in IR mode) |
| Working distance | 470 mm |
| Texture / Colors | Yes |
| Outer dimensions | 108 x 110 x 237 mm |
| Operating temperature | 0–40 °C |
